TL250 (Dunker Brushed Moter)

  • ES200/SLH250(SLM) compatible profile and hardware
  • Dunkermotoren GR 63×55 motor, dual motor driving mode available
  • Double overlapped or triple overlapped sliding
  • Driving & controlling by either ES200 or SLH250(SLM) system
  • Highly customized for super heavy load commercial telescopic doors.
Ask a question

TL250 (Dunker Brushed Moter)

* Required fields

Size guide Share
TL250 (Dunker Brushed Moter)

TL250 (Dunker Brushed Moter)

Regular price $2,990.00
Sale price $2,990.00 Regular price
Unit price
DESCRIPTION
Dunkermotoren GR 63*55
● DIN 18650 - 1 million test cycles at 4 000 cycles per day
● EB16005
TL250 controller function programs
● Off
● Automatic
● Permanent open
● Partial open
● Exit only
● Night-bank switch
High molecular polymer material, resistant to fatigue and wear Noiseless Track with rubber strips

Description

Intelligent microprocessor control automatic telescopic door system, which uses the compatible Kaba/Gilgen SLM profile and hardware, the control and driving system can be either SL250(SLM) or ES200.To maximize the opening width, this automatic door control system has 2 or 3 overlapped door panels which are fixed on 2 or 3 sliding guide ways (rails) and move to same direction. Compared to regular sliding door, it tremendously increases the clear door opening.



Specification

Door parameters TL250 (Dunker Brushed Moter)
Passage width LW 1800-4000 mm
Panel weight max. 4x100 kg
Passage height 2100-3000mm
Technische gegevens TL250 (Dunker Brushed Moter)
Height 95 mm
Depth 230 mm
Opening and closing force max. 150N
Opening speed  10-70 cm/s
Closing speed  10-50 cm/s
Hold time - open 0-180 s
Moter 60V/100W Brushed moter
Voltage, frequency 230 V,50/60 Hz
Power consumption 360 W



SLH250 Operator option

COMMON OPTIONS(Not included in the package)
