1.1 Symbols and Illustrations
Warning notices
In these instructions, warning notices are used to warn against material damage and injuries.
- Always read and observe these warning notices.
- Observe all measures marked with the warning symbol and warning word.
| Warning Symbol | Warning Word | Meaning |
|---|---|---|
| DANGER | Danger to persons. Non-compliance will result in death or serious injuries. | |
| WARNING | Danger to persons. Non-compliance can result in death or serious injuries. | |
| CAUTION | Danger to persons. Non-compliance can result in minor injuries. |
Further symbols and illustrations
Important information and technical notes are highlighted to explain correct operation.
| Symbol | Meaning |
|---|---|
| Important Note | Information to prevent property damage, to understand or optimise the operation sequences. |
| Additional Information | Provides supplementary details. |
- Symbol for an action: This means you have to do something.
- If there are several actions to be taken, keep to the given order.
1.2 Revisions and Validity
Version 02: valid for Slimdrive SL NT product family from model year 2021.
1.3 Product Liability
In compliance with the liability of the manufacturer for his products as defined in the German "Product Liability Act", compliance with the information contained in this brochure (product information and intended use, misuse, product performance, product maintenance, obligations to provide information and instructions) must be ensured. Failure to comply releases the manufacturer from his statutory liability.
1.4 Reference Documents
| Type | Name |
|---|---|
| Wiring diagram | Automatic sliding doors DCU1-NT/DCU1-2M-NT |
| Additional wiring diagram | Automatic sliding doors DCU1-2M-NT, door controller DCU 1-2M-NT for automatic sliding doors on escape routes, FR-variants DUO, LL, RWS |
| User manual | Automatic sliding door systems |
| Faults and corrective measures | DCU1-NT/DCU1-2M-NT electronic drive for automatic sliding doors |
| Cable plan | Automatic sliding door systems |
| Safety analysis | Automatic sliding doors |
| Pre-assembly instructions | Slimdrive SL NT product family |
| Installation instructions | Slimdrive SL NT girder section and fixed panel |
| Additional installation instructions | Slimdrive SL NT GGS |
These documents are subject to change. Use only the most recent version.
